Mindray 35C50EB New Compatible Convex Array Ultrasound Transducer Probe
- Brand
- Mindray
- Category
- Compatible Ultrasound Probe
Product Information
The Mindray 35C50EB is a compatible convex array ultrasound transducer for selected Mindray DP-series systems. Its 2.0-5.0 MHz frequency range is listed for abdominal, obstetric and gynecologic, urological, and pediatric imaging. A biopsy needle guide is available for this model.
Specifications
| Specification | Details |
|---|---|
| Probe model | Mindray 35C50EB |
| Product type | Compatible ultrasound transducer probe |
| Array type | Convex array |
| Frequency range | 2.0-5.0 MHz |
| Applications | Abdominal, obstetric and gynecologic, urological, and pediatric imaging |
| Biopsy needle guide | Available |
Typical clinical use
Abdominal applications include organ surveys and upper-abdomen scanning. The same probe is also listed for obstetric and gynecologic examinations, alongside its abdominal applications.
Urological applications include kidney and bladder imaging. Pediatric and general-purpose scanning are also listed applications for the 35C50EB.
Compatibility & fit
The 35C50EB is listed for six Mindray DP-series ultrasound systems. The DP-1100 entry specifically identifies the Plus model, so the full system designation matters when selecting a replacement.
| Compatible equipment | Fit notes |
|---|---|
| Mindray DP-10; DP-20 | Listed compatible systems for the 35C50EB convex array probe. |
| Mindray DP-1100 Plus | The listed designation includes Plus. |
| Mindray DP-2200; DP-3300; DP-7700 | Listed compatible systems for the 35C50EB convex array probe. |
Use the exact DP system model when discussing replacement-probe fit. The existing product information calls for connector and functional compatibility to be checked against the machine at the time of order.
Provide your exact Mindray DP system model when enquiring about probe fit, connector compatibility, or the available biopsy needle guide.
The Mindray 35C50EB offers 2.0-5.0 MHz compatible convex array imaging for abdominal, OB/GYN, urological and pediatric applications on Mindray DP-10, DP-20, DP-1100 Plus, DP-2200, DP-3300 and DP-7700 systems, with a biopsy needle guide available.
